Grubość blachy ze stali nierdzewnej walcowanej na zimno lub na gorąco 6 - 80 mm Q235 Q345 B C D E
Product Details
| Nazwa produktu: | Płyta ze stali stopowej | Standard: | AISI, ASTM, BS, DIN, JIS |
|---|---|---|---|
| Podanie: | Płyta statku | Technika: | walcowane na zimno / walcowane na gorąco |
| Podkreślić |
płyta zbiornika ciśnieniowego,płyta stalowa statku |
||
Product Description
Q235 Q345 BCDE walcowana na zimno / walcowana na gorąco blacha stalowa o grubości 6-80 mm
Q345B / C / D / E
1) Standard: GB
2) Grubość: 6-80 mm
3) Szerokość: 1600-3200 mm
4) Długość: 6000-14000 mm
5)) Wysoka jakość niska cena
Składnik chemiczny (% wag.)
| do | Si | Mn | P. | S. | V. | Uwaga | Glin | Ti | |
| Q345A | ≤0,20 | ≤0,55 | 1,00–1,60 | ≤0,045 | ≤0,045 | 0,02–0,15 | 0,015–0,060 | - | 0,02–0,20 |
| Q345B | ≤0,20 | ≤0,55 | 1,00–1,60 | ≤0,040 | ≤0,040 | 0,02–0,15 | 0,015–0,060 | - | 0,02–0,20 |
| Q345C | ≤0,20 | ≤0,55 | 1,00–1,60 | ≤0,035 | ≤0,035 | 0,02–0,15 | 0,015–0,060 | ≥0,015 | 0,02–0,20 |
| Q345D | ≤0,18 | ≤0,55 | 1,00–1,60 | ≤0,030 | ≤0,030 | 0,02–0,15 | 0,015–0,060 | ≥0,015 | 0,02–0,20 |
| Q345E | ≤0,18 | ≤0,55 | 1,00–1,60 | ≤0,025 | ≤0,025 | 0,02–0,15 | 0,015–0,060 | ≥0,015 | 0,02–0,20 |
Właściwości mechaniczne
| grubość | temperatura badania (° c) | Wydłużenie(%) | dowód stresu (Mpa) | Trentile Strenth (Mpa) | |
| Q345A | ≤16 | - | 21 | 345 | 470–630 |
| Q345B | ≤16 | 20 | 21 | 345 | 470–630 |
| Q345C | 16–35 | 0 | 22 | ≥325 | 470–630 |
| Q345D | 35–50 | -20 | 22 | ≥295 | 470–630 |
| Q345E | 50–100 | -40 | 22 | ≥275 | 470–630 |
Nasze produkty
| Seria produktów | Standard wykonawczy | Stopień | Klasa | Grubość (mm) |
Dostawa Stan |
| Stal konstrukcyjna niskostopowa | GB / T 1591-2008GB / T 3274-2007 | Q345 | A, B | 6 ~ 150 | AR |
| PŁYTA CD | 6 ~ 150 | CR | |||
| mi | 6 ~ 150 | TMCP | |||
| Q390 | A, B, C, D, E | 6 ~ 150 | CR | ||
| Q420 | 6 ~ 150 | TMCP | |||
| Q500 | 6 ~ 100 | TMCP | |||
| Q550 | 6 ~ 100 | ||||
| Q620 | 6 ~ 80 | ||||
| Q690 | 6 ~ 80 | ||||
| GB / T 28410-2012 | Q235FT | B, C, D, E. | 5 ~ 150 | AR, CR | |
| Q275FT | C, D, E, F. | 5 ~ 150 | AR, CR | ||
| Q345FT | C, D, E, F. | 5 ~ 150 | AR, CR | ||
| Q420FT | C, D, E, F. | 5 ~ 150 | AR, CR | ||
| Q460FT | C, D, E, F. | 5 ~ 150 | AR, CR | ||
| EN 10025-4: 2004 | S275M / ML | - | 6 ~ 60 | TMCP | |
| S355M / ML | |||||
| S420M / ML | |||||
| S460M / ML | |||||
| JIS G3106: 2008 |
SM400 SM490 |
ABC | 6 ~ 150 | AR | |
| ABC | 6 ~ 150 | CR | |||
| YA, YB | |||||
| SM520 | PNE | 6 ~ 80 | TMCP | ||
| SM570 | 6 ~ 80 | ||||
| ASTM A572 / A572M-12 | Gr42 | - | 6 ~ 150 | AR | |
| Gr50 | - | 6 ~ 100 | CR | ||
| Gr55 | - | 6 ~ 100 | |||
| Gr60 | - | 6 ~ 80 |
TMCP |
Product Highlights
Q235 Q345 BCDE walcowana na zimno / walcowana na gorąco blacha stalowa o grubości 6-80 mm Q345B / C / D / E 1) Standard: GB 2) Grubość: 6-80 mm 3) Szerokość: 1600-3200 mm 4) Długość: 6000-14000 mm 5)) Wysoka jakość niska cena Składnik chemiczny (% wag.) do Si Mn P. S. V. Uwaga Glin Ti Q345A ≤0,20 ≤0...
